Simpson Strong-Tie 6x 18 ga Galvanized Adjustable Post Cap
Model #LCE4Item #107734UPC 00707392658306
Tap to view
Product overview
These connectors are always installed in pairs and connect 6X lumber at right angles. Eliminates driving nails into end grain. Nails can be added in triangle holes to increase uplift load capacity. Install with (Min) 8-16d fastener on beam, 6-16d on post; (max) 10-16d fastener on beam, 10-16d on post. 6-1/2" L 18-gauge galvanized steel. Box contains 20 lefts and 20 rights.
- Always install in pairs; universal design eliminates need for rights and lefts
- Stronger than angled nailing or screw fastening
- Eliminates nailing into end grain
- Tested and approved for mitered end conditions
Product manuals and information
Specifications
| Material | Steel |
| Type | Adjustable |
| Finish | Galvanized |
| Size | 6x |
| Gauge | 18 ga |
| Install With | 10-16d on beam, 10-16d on post (maximum) |
| Dimensions | 6-1/2\ L |
| Brand | Simpson Strong-Tie |
| UPC | 00707392658306 |
| Product type | Post Cap |
