Abbott 2 In. Polypropylene Bulkhead Fitting
Model #TF200PEItem #441305UPC 00023537383507
Tap to view
Product overview
Abbott Polypropylene Bulkhead Fitting allows piping connections to a tank. Locknut thread onto the body and holds it in place. Should be hand tightened and then another 1/4 turn. Locknuts put pressure on the gasket, allowing for a tight seal.
- Easy installation
- Allows piping connects to a tank
- Durable
- Locknut puts pressure on the gasket to create a tight seal
- Over-tightening may distort gasket and cause leaks
Specifications
| Material | Polypropylene |
| Connection Type | Female |
| Fitting Size | 2 In. |
| Pressure Rating (psi) | 75 |
| Maximum Working Temperature (F) | 140 |
| Fitting Type | Bulkhead |
| Brand | Abbott Rubber |
| UPC | 00023537383507 |
| Product type | Polypropylene Adapter |
