Gardner Bender SpikeStopper 75kA Whole Home Surge Protection Device
Model #ER3M-1025-1S1Item #531111UPC 00032076954086
Tap to view
Product overview
The SpikeStopper Whole Home Surge Protector meets the NEC 2023 requirement of surge protection on new homes and other dwellings such as dormitories, nursing care, and hotel rooms with kitchenettes. The unit protects appliances from power surges including: washers, dryers, stoves, refrigerators, electronics, HVAC, and more. Easy installation at the main electrical panel or other residential installation locations including electrical panels and disconnects, condensing units, furnaces, heat pumps, irrigation and pool pumps. Recommended installation by a qualified electrician.
- 75 kA total protection
- Voltage: 120/240VAC, split phase, 3W+G
- Universal 4-wire installation
- Frequency: 50 to 60Hz
- Temperature: -35 Deg C to 40 Deg C
- NEMA 4X indoor/outdoor Rated enclosure
- cUL Listed; UL Type 4 enclosure, liquid-tight
- Compatible with all manufacturers' panels
- Includes 1/2 In. locknut required for installation
- 5 Yr. warranty
Specifications
| Voltage | 120/240VAC, Split Phase 3W+G |
| Mount Type | Panel Mount |
| Certification | cUL Listed |
| Maximum Continuous Operating Voltage | 120/240 |
| Short Circuit Rating | 10 kA |
| SPD Type | Type 1 & Type 2 |
| Nominal Discharge Current | 10 kA |
| Width (In.) | 2.125 |
| Height (In.) | 2.5 |
| Length (In.) | 2.5 |
| Brand | Gardner Bender |
| UPC | 00032076954086 |
| Product type | Whole House Surge Protector |
